JIA-626information
FIBER OPTIC INTERCONNECTING PLUG PUSH-COMPRESSION TESTER
This tester is used to force the toe of Fiber Optic Interconnecting Plug along by axle, then measure the compressive value of altered position.

Capacity:10㎏
Resolution: 1/10000
Measuring accuracy of altered
position:0.01㎜

JIA-627information
FIBER OPTIC CONNECTOR JOLT TESTER
This tester uses mechanical hand to pick up specimen and let it drop freely for imitating jolt action.

Height of drop:5～40㎜ (adjustable)
Counter:electronic type 6 digits
Driving method: pneumatic type

JIA-628information
FIBER OPTIC CONNECTOR VIBRATION TESTER
Connect the optical cable to the tester, use10-50-10 Hz period of vibrate for two hours in each X-axis and Z-axis direction, then check its optic characteristics.

Amplitude of vibration:1.5㎜ P-P
Frequency:10～50～10HZ
Timer: X-Zaxis 0～999min

JIA-629information
FIBER OPTIC CONNECTOR FLEXING TESTER
Specimen is to be twisted 90° in left ＆ right dirction during operating, we can chack whether the optic charactristics of specimen is influenced or not after 200testing times achieved.

Length of specimen:1～2m
Bending radius:25，30㎜
each one setLoad:500g
Freqency:10～30times/min (adjustable)
Counter:electronic type 6 digits

JIA-630information
FIBER OPTIC CONNECTOR PLUGGING & PLUCKING TESTER
Adjust the motive frequency by pneumatic drive, in order to repeat plug-in, and pull-out.and in the meantime, it is allowed to cooperate with optic receiver and computer for Auto-control.

Driving method:pneumatic type
Frequency:10～30times (adjustable)
Counter:electronic type 6 digits

JIA-631information
FIBER OPTIC CONNECTOR TWIST TESTER
Hang a 500g load on the lower end of FIBER OPTIC CABLE the load is twisting 180° in both forward ＆ backward directions till the specified times achieved, after that, test its characteristics.

Length of specimen:1～2m
Load:500g
Torque degree:in each left and rignt side
Frequency:10times/min
Counter:electronic type 6 digits

JIA-632information
PLUG SOCKET RETENTION TESTER
This tester is used to test max. retention of Fiber Optic Connector during polling plug.

Capacity:10㎏
Accuracy:±1﹪
Resolution:1/10000

JIA-517C information
Static Friction Tester (on-line)
The test is suitable for the light-electrical industry plastic membrane, the quality packing plastic membrane, papers, cellophanes… on friction force and static /kinetic friction coefficient.
Selects and purchases for on-line system.
